MULTIFUNCTIONAL SPRING DRIVEN HOSE REEL
Hose I.D.:Up to 1/2"
Hose Length:Up to 65'/20m
Max Pressure4800PSI/330bar
Inlet/Outlet:Up to 1/2"
Description
-
Automatic hose guiding system is available on HR783, allows an automatic rewinding of hoses in an orderly way, without any pile up
-
Speed control device makes an automatic rewinding of hoses in constant speed and safer way, keep the rewind speed under control all the time
-
Hose can be stopped at any point as your desired
-
Newly designed swivel and hose inlet connection seal against leaks
-
Durable construction made from high quality impact resistant. polypropylene, light weight and more compact
-
Superior bend radius of hybrid polymer hose help eliminate kinks, no memory
-
Hose maximum temperature -40°F~176°F (-40°C~80°C)
-
36"/0.9m lead-in hose is included
Technical Data
| Item No. | Hose l.D. | Hose Length | Working Pressure | Inlet/Outlet | Inlet Thread Type | Hose Material | Application |
| HR783.01 | 3/8" | 65'/20m | 300PSI/20Bar | 1/4" | NPT | Hybrid Polymer | Air/Water |
| HR783.03 | 1/2" | 50'/15m | 300PSI/20Bar | 3/8" | NPT | Hybrid Polymer | Air/Water |
| HR783.04 | 1/2" | 50'/15m | 300PSI/20Bar | 1/2" | NPT | Hybrid Polymer | Air/Water |
| HR783.05 | 3/8" | 20m | 20Bar | 3/8" | BSPT | Hybrid Polymer | Air/Water |
| HR783.06 | 1/2" | 15m | 20Bar | 1/2" | BSPT | Hybrid Polymer | Air/Water |
